| Peso | 0,7 kg |
|---|
| Sensore di immagine | 1/2.7 Progressive Scan CMOS |
|---|
| Shutter Speed | 1/3 to 1/10000 s |
|---|
| Slow Shutter | S |
|---|
| Luminosit minima | 0.005 Lux; 0 Lux with IR/White light |
|---|
| Meccanismo giorno/notte | IR Cut Filter |
|---|
| Day/Night Switch | Unified/ Scheduled/ Auto |
|---|
| Type | Fixed Focal Lens |
|---|
| Focal Length | 2.8 mm |
|---|
| Aperture | F1.6 |
|---|
| FOV | Horizontal FOV: 100 , Vertical FOV: 54 , Diagonal FOV: 118 |
|---|
| Lens Mount | M12P 0.5 |
|---|
| Detect | 64 m (210 ft) |
|---|
| Observe | 27 m (89 ft) |
|---|
| Recognize | 13 m (43 ft) |
|---|
| Identify | 6 m (20 ft) |
|---|
| Angle Adjustment (Manual) | Range: Pan: 0 to 360 , Tilt: 0 to 85 , Rotation: 0 to 360 |
|---|
| Quantity | 4 |
|---|
| Range | 30m |
|---|
| Wavelength | 850nm |
|---|
| Illuminator On/Off Control | Auto/Scheduled/Always on/Always off |
|---|
| Max. Resolution | 2688 x 1520 |
|---|
| 50Hz | 1fps, 5fps, 10fps, 15fps, 20fps, 25fps |
|---|
| 60Hz | 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps |
|---|
| Resolution | 848×480, 704×576, 640×480, 640×360, 352×288, 320×240 |
|---|
| Bit Rate Control | CBR, VBR |
|---|
| Main Stream | 256 Kbps to 6 Mbps |
|---|
| Sub-Stream | 64 Kbps to 512 Kbps |
|---|
| H.264 Type | High Profile |
|---|
| H.264+ | Main Stream Supported |
|---|
| H.265 Type | Main Profile |
|---|
| H.265+ | Main Stream Supported |
|---|
| Image Enhancement | BLC/3D DNR/HLC/SmartIR |
|---|
| Wide Dynamic Range | 120 dB |
|---|
| SNR | 52 dB |
|---|
| Image Parameters Switch | S |
|---|
| Privacy Mask | Up to 4 Masks |
|---|
| ROI | 1 Region |
|---|
| OSD Setting | S |
|---|
| Comunicazione audio | Two-Way Audio |
|---|
| Ingresso audio | S |
|---|
| Uscita audio | S |
|---|
| Codec audio | S |
|---|
| Audio Sampling Rate | 8KHz |
|---|
| Environment Noise Filtering | S |
|---|
| Audio Bit Rate | 64 Kbps(G.711 alaw) |
|---|
| Protocol | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP |
|---|
| ONVIF | S |
|---|
| API | ONVIF Profile S/T/G |
|---|
| Simultaneous Live View | 3 Main Streams 3 Sub-Streams |
|---|
| Client | VIGI App, VIGI Security Manager, Web UI, VIGI VMS, VIGI Cloud VMS |
|---|
| Cloud | S |
|---|
| Sicurezza | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
|---|
| Linkage Method | N/A |
|---|
| Output Notification | Message Push |
|---|
| Deep Learning Function | People Vehicle Analytics: Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier. |
|---|
| Interfaccia di rete | 1x RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
|---|
| Allarme | N/A |
|---|
| Reset Button | S |
|---|
| Power | DC Power Port |
|---|
| On-board Storage | Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB |
|---|
| Built-in Microphone | S ; Records Anything Going on within a 15-ft Radius of the Camera |
|---|
| Built-in Speaker | S |
|---|
| Audio | N/A |
|---|
| Operating Temperature | -30 60 C |
|---|
| Storage Temperature | -40 60 C |
|---|
| Operating Humidity | 95% or Less (Non-Condensing) |
|---|
| Storage Humidity | 95% or Less (Non-Condensing) |
|---|
| Material | Metal |
|---|
| Net Weight | 0.48 Kg |
|---|
| PoE | 802.3af/at, class 0, Max. 12 W |
|---|
| Protection | IP67 |
|---|
| Product Dimensions (L x W x H) | 4.4 4.4 3.3 in (111 111 83.7 mm) |
|---|
| Certifications | CE, NTRA, VCCI, KC, BSMI, FCC, IC |
|---|
| Marca | TP-LINK |
|---|
