| Peso | 4,2 kg |
|---|
| Interfaccia | 48 10/100/1000 Mbps RJ45 Ports, 4 1/10 Gbps SFP+ Slots, 1 USB 2.0 Ports, 1 RJ45 Console Port, 1 USB Type-C Console Port |
|---|
| Marca | |
|---|
| Numero ventole | Fanless |
|---|
| Alimentazione | 100-240V AC~50/60Hz |
|---|
| Dimensioni (L x P x A) | 17.3 8.7 1.7 in (440 220 44 mm) |
|---|
| Tipo di montaggio | Rackmountable |
|---|
| Max. Power Consumption | 34.34 W (110 V/60 Hz) |
|---|
| Max. Heat Dissipation | 117.10 BTU/hr (110 V/60 Hz) |
|---|
| Capacit di switching | 176 Gbps per Unit |
|---|
| Stacking | Stacking Number: 4, Stacking Port: 10G SFP+ Slot (all uplink ports can be used as stacking ports), Stack Bandwidth: Up to 40 Gbps (4 stacking ports) |
|---|
| Packet Forwarding Rate | 130.94 Mpps |
|---|
| Tabella ARP | 16 K |
|---|
| Buffer (pacchetti) | 3 MB |
|---|
| Jumbo frame | 9 KB |
|---|
| Caratteristiche avanzate | Automatic Device Discovery , Batch Configuration , Batch Firmware Upgrading , Intelligent Network Monitoring , Abnormal Event Warnings , Unified Configuration , Reboot Schedule |
|---|
| ISP Features | 802.3ah Ethernet Link OAM, L2PT (Layer 2 Protocol Tunneling), Device Link Detect Protocol (DLDP), DDM, sFlow |
|---|
| Port Isolation | S |
|---|
| CPU-Defend | S |
|---|
| ARP Inspection (Dynamic ARP Inspection) | S |
|---|
| DoS Defend | S |
|---|
| IP-MAC-Port Binding | 1,024 Entries, DHCP Snooping, ARP Inspection, IPv4 Source Guard |
|---|
| IPv6-MAC-Port Binding | 1,024 Entries, DHCPv6 Snooping, ND Detection, ND Snooping, IPv6 Source Guard |
|---|
| DHCP Filter | S |
|---|
| Static/Dynamic Port Security | Up to 64 MAC addresses per port |
|---|
| 802.1X | Port base authentication, Mac base authentication, VLAN Assignment, MAB, Guest VLAN, RADIUS authentication and accountability support |
|---|
| AAA (including TACACS+) | S |
|---|
| Secure web management | HTTPS with SSLv3/TLS 1.2 |
|---|
| IP/Port/MAC-based access control | S |
|---|
| Omada App | Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller |
|---|
| Centralized Management | Omada Cloud-Based Controller, Omada Hardware Controller, Omada Software Controller |
|---|
| Cloud Access | Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller |
|---|
| Zero-Touch Provisioning | Yes. Requiring the use of the Omada Cloud-Based Controller |
|---|
| Contenuto della confezione | SG5452X Switch, Power Cord, Console Cable, Rackmount Kit, Rubber Feet, Quick Installation Guide |
|---|
| Requisiti di sistema | Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8/10/11, MAC OS, NetWare , UNIX or Linux |
|---|
| Ambiente | Operating Temperature: -5 C to 45 C (23 F to 113 F), Storage Temperature: -40 C to 70 ℃ (-40 ℉ to 158 ℉), Operating Humidity: 10 90% RH non-condensing, Storage Humidity: 5 90% RH non-condensing |
|---|
| Marca | 48P |
|---|
